MSI Pro B860M-A WIFI DDR5 LGA1851 Motherboard

Rp 2.950.000

In stock

Pengiriman via Gosend ke sesama Batam

Socket LGA 1700 – Mendukung prosesor Intel® Core™ Generasi ke-14, 13, dan 12
Chipset Intel B860 – Stabil dan efisien untuk kebutuhan kerja dan gaming ringan
Dukungan DDR5 hingga 256GB – Kapasitas besar dan kecepatan tinggi untuk multitasking
Dual M.2 PCIe 4.0 – Slot M.2 ganda untuk SSD NVMe berkecepatan tinggi
Wi-Fi 7 & Bluetooth 5.4 – Koneksi nirkabel modern untuk transfer cepat dan latensi rendah
2.5G LAN – Koneksi kabel yang lebih cepat untuk streaming dan gaming
HDMI & DisplayPort – Output layar untuk konfigurasi multi-monitor, mendukung resolusi tinggi
Audio Boost – Peningkatan kualitas audio untuk multimedia dan komunikasi
EZ Debug LED & M.2 Shield Frozr – Memudahkan troubleshooting dan pendinginan SSD
Desain PRO Series – Tampilan profesional dengan build quality yang tahan lama
Garansi Resmi 3 Tahun – Perlindungan produk jangka panjang dari MSI Indonesia

Categories:

KOMPONEN PC

Details
More Information

PRO B860M-A WIFI

MSI PRO B860M-A WIFI hadir dengan socket LGA 1851 dan dukungan DDR5 hingga 192GB, siap memberikan performa maksimal untuk prosesor Intel generasi terbaru. Dilengkapi Wi-Fi 7, 2.5G LAN, dan Dual M.2 PCIe 4.0, motherboard ini menawarkan kecepatan koneksi dan transfer data super cepat. Fitur seperti Audio Boost, EZ Debug LED, dan M.2 Shield Frozr menjamin pengalaman penggunaan yang stabil dan efisien. Dengan garansi resmi 3 tahun, MSI PRO B860M-A WIFI menjadi pilihan ideal untuk PC kerja maupun gaming modern.

Specifications

Chipset	Intel® B860 Chipset
CPU	Supports Intel® Core™ Ultra Processors (Series 2) LGA 1851
Memory	4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 8800+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 5600+ MT/s Supports Intel® POR Speed and JEDEC Speed Supports Memory Overclocking and Intel® XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM
Onboard Graphics	1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* 1x Type-C DisplayPort Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Slot	4x PCI-E x16 slot (Qty) PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset)
Wireless LAN & Bluetooth®	Intel® Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth® 5.4*, MLO, 4KQAM 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2. ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.
Audio	Realtek® ALC897 Codec 7.1-Channel High Definition Audio
Storage	3x M.2 (Qty) M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2 , supports 2280 devices 4x SATA 6G (Qty) *Please refer to the manual for M.2 SSD heatsink restrictions.
RAID	Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Onboard Thunderbolt	1x Thunderbolt4 ports (Rear) Supports up to 40Gbps transfer rate with Thunderbolt devices Supports up to 20Gbps transfer rate with USB4 devices Supports up to 10Gbps transfer rate with USB 3.2 devices Supports up to 5V/3A,15W power charging Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices Supports up to 8K display
USB	2x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 1x USB 5Gbps Type C (Rear) 4x USB 5Gbps Type A (Front) 1x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Front)
LAN	Realtek® 8126 5Gbps LAN
Internal IO	1x Thunderbolt5 card connector(JTBT5, support RTD3) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports
LED FEATURE	4x EZ Debug LED 1x EZ Memory Detection LED
BACK PANEL PORTS	1x DisplayPort 1x Keyboard / Mouse 2x USB 5Gbps Type-A 1x 5G LAN 1x Wi-Fi / Bluetooth 1x Audio Connectors 1x HDMI™ 1x Thunderbolt™ 4 40Gbps (Type-C) 2x USB 2.0 1x Clear CMOS Button 1x USB 10Gbps Type-A 1x USB 5Gbps Type-C
Form Factor	mATX 243.84mmx243.84mm

More Information
Socket	INTEL LGA1851
Price	Rp 2.950.000
